| Applicable Material | | Steel | Stainless Steel | Super-Alloys / Titanium | | Min D.O.C. | 0.8 mm |
| Application | | Holder for W-Insert 80° | | Depth of Cut Maximum (APMX) | 3 mm |
| Corner Radius (RE) | 0.8 mm | Min. Turning Feed (ft(min)) | 0.13 mm |
| Cutting Edge Length (L) | 6.1 mm | Max. Turning Feed (ft(max)) | 0.5 mm |
| Insert Thickness (S) | 4.76 mm | Measurement Type | Metric |
| Inscribed Circle Diameter (IC) | 9.52 mm | Body Material | Carbide |
| Coating | TiAlN+TiN | Unit | M |
| Grade | TT9080 |
Product Features
| Family Description | for medium roughing / stainless steel | FamilyName | WNMG EM |
| COO | South Korea | BrandName | Ingersoll GMBH |
Shipping Info
Weight per item
0.0065
Name
Turning Indexable Inserts
FamilyName
WNMG EM
BrandName
Ingersoll GMBH
